Guitar Model: 2026
Guitar Brand: Firefly FFTL Dragon
Install Time: 0 - 10 minutes
Install notes: Don't tin the wire leads as doing so will make them to large to fit in the wire harness.
Installed By: Owner
How does it sound?: Better
Tonal variety: More Tonal Variety
Noise / hum level: Lower Noise
Main reason for purchase: Increase Tonal Variety
Expected results: Series humbucker mode.
What where the results?: Series humbucker mode with less noise and better tone when using the volume knob.
Was it worth it?: Yes
Why?: Now I get more tonal variety with lower noise and better tone.
Reviewer Type: Gigging Musician
While the 4-way Tele switch isn't a new concept, Obsidian Wire made it amazingly simple for me to add the 'humbucker mode' (both pickups in series) without needing to solder anything. Humbucker mode is punchier in the low midrange, which is great for me as a solo guitar performer, as I don't lose the richness as I do with the traditional parallel setting. Plus, the treble bleed gives me a solid tone regardless of the volume knob position. Now I want to install this in every ASAT and T-style guitar I own. I couldn't be happier!
I use the Obsidian prewired electronics for my new builds as opposed to replacement wiring. It looks clean and professional, and they use all top quality components. It has been a little tricky installing into the LP since the circuit board is flat and the body top is arched, but it is not too hard to get it set by adding set nuts underneath and removing a bit of wood.
Options for 250k OHM pots would be nice. I use Lace Alumitones that are humbuckers, but prefer 250k Ohm pots. This becomes even more apparent when switching to single coil mode. I have had to add 470k resistors in parallel to try to compensate. Other than that - I love this setup!
Probably the best wiring harness available today. Gilmore mod is excellent. Quality components.
Guitar Model: Squier Classic Vibe 70s Jazz Bass
Guitar Brand: Squier
Install Time: 0 - 10 minutes
Installed By: Owner
How does it sound?: Better
Tonal variety: More Tonal Variety
Noise / hum level: Lower Noise
Main reason for purchase: Increase Tonal Variety, Faster Pickup Swaps
Was it worth it?: Yes
Reviewer Type: Home Player
Awesome harness, super easy to install, sounds great! I especially love the 250k/500k selector switch because I have Dimarzio Relentless J pickups.
Guitar Model: Classic Vibe 70 HT HSS Strat
Guitar Brand: Swuire
Install notes: All I had to do was enlarge the holes in my pickguard, otherwise fit perfectly.
I upgraded my Squire Classic Vibe 70s HT HSS with this. I already liked the tone of the guitar, but literally when I played my first few strums after installation my jaw was hanging open! I have no idea how it improved the sound of the guitar this much, but wow! I’m so impressed.
It’s true what they say, “install is easy, not instant”
This pre wired harnesses are my new go to way to upgrade. The ease and quality is totally worth the extra price.
Guitar Model: 2013 Les Paul Studio
Guitar Brand: Gibson
Install Time: 11 - 20 minutes
Install notes: Make sure to have a kit of fine pliers because the Gibson pickup wires are really thin.
Installed By: Owner
Perfect to replace the oem electronics on my 2013 Gibson Les Paul studio wich had some electronic problems. Easy install, works great with the Gibson pickups, also the split coil. Better sounding, less noise. I had already installed a kit in my Stratocaster and just as this one I the Gibson one seems a great kit to me!
Guitar Model: 2004 E SE LT
Guitar Brand: Edwards
Install Time: 11 - 20 minutes
Install notes: Actual install also required figuring out that the little hump between the rear pot and switch needed some clearance to fit. Took an additional 10-15 minutes. I was expecting that for the pot, though, so all good.
Very well done. Retrofit worked well after a bit of carving. Quality, feel, and tone was just what I was looking for. Great experience and exceptional product. :)
Guitar Model: Strat
Install Time: 20 - 30 minutes
Installed By: Owner
How does it sound?: Better
Tonal variety: More Tonal Variety
Amazing job! Esasy to install. Top quality
Guitar Model: Home assembled Jazz Bazz, based on 70’s Fender’s JB.
Guitar Brand: No brand / home assembled
Install Time: 0 - 10 minutes
Install notes: So easy to install, a little kid could do it.
Installed By: Owner
How does it sound?: Better
Tonal variety: More Tonal Variety
Noise / hum level: Same
Main reason for purchase: New Build, New Build
Expected results: Solid build and great quality.
What where the results?: Solid build and great quality.
Was it worth it?: Yes
Why?: The others make things I could do by myself. This one is real work. Not just pots and wires soldered on them.
Reviewer Type: Tech / Builder
Quality is impeccable, service is just magic. Great product and nice team at O.W
I would have loved a chamfered border on the plate, but it’s already beautiful like that.
Guitar Model: Les Paul Custom
Guitar Brand: Gibson
Main reason for purchase: Repair / Replacement
I purchased a PC board from this company almost a month ago. It was almost $200. I got a follow up email immediately, but it took almost a week to receive a tracking number. The tracking number has been invalid from the start. Customer service has refused to respond to even one of my several attempts to contact them in order to merely either provide me with the product or make resolution. I feel like I’m almost being trolled at this point because their customer service is literally that nonexistent. I’m gonna have to go through my bank to get my money back. What a huge letdown.
